Inicio /Productos/Cordón de remiendo de la fibra óptica/Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss

1km
MOQ
Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Tipo de conector: SC-LC o personalizar
Longitud: 1m 2m 3m o personalizado
Material: PVC/LSZH, hilo de aramida
Color: Amarillo/Negro
Artículo: cable de conexión de fibra óptica
Repetibilidad: ≤ 0,2 dB
recuento de fibras: Simplex o Dúplex
Control de calidad: 100% prueba antes del envío
Resaltar:

duplex OS2 fiber optic patch cord

,

SC to LC single mode patch cable

,

low loss fiber optic patch cord
Información básica
Lugar de origen: Cantón, China
Nombre de la marca: Jiqian/Customize/ OEM
Certificación: ISO 9001,ROHS CE-EMC FCC SDOC
Número de modelo: Cordón de parche SC-LC
Pago y Envío Términos
Detalles de empaquetado: Exportar caja de dibujos animados
Tiempo de entrega: 5-8 días laborables
Condiciones de pago: Western Union, T/T, LC, Alipay
Capacidad de la fuente: 1000pcs por día
Descripción de producto

Simplex Duplex SC LC Patch Cord SM OS2 9/125 PVC LSZH Fiber Optic Cable



Product Features

  • OS2 9/125μm singlemode fiber for long distance high speed transmission

  • Available in simplex and duplex configurations

  • SC to LC connectors with PC UPC or APC polish options

  • Low insertion loss and high return loss for stable performance

  • Excellent repeatability and interchangeability

  • PVC or LSZH jacket for flexible indoor use

Application Scenarios

  • CATV and telecom network connections

  • Optical switches and transmission equipment

  • Optical transmitter and receiver interconnection

  • ODF and terminal box patching

  • Data center and enterprise fiber cabling systems



Optical Characteristics

Mode SM MM
Polish UPC APC APC
Insertion Loss Typical ≤0.2dB Maximum ≤0.3dB ≤0.25dB
Return Loss ≥50dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Repeatability ≤0.1dB
Durability ≤0.2dB(1000 times mating)
Tensile Strengh >10kg
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB(+25+65 93 R.H.100 hours)



Technical Data

Type



Standard,Master



Style



LC,SC,ST,FC.MU,DIN,D4,MPO,SC APC,FC/IAPC,LCIAPC.MU/APC



Fiber



Singlemode/Multimode

50/125,62.5/125 (Multimode) OM2&OM1

50/125,10G(Multimode)OM3



Cable



Simplex,Duplex

Φ3.0mm,Φ20mm,Φ0.9mm

PVC or LSZH



Polishing Manner



UPC,SPC,APC (8°&6°)



Insertion Loss



≤0.1dB(For Singlemode Master)

≤0.25dB(ForSinglemodeStandard)

≤0.25dB(ForMultimode)

Tested by JDSRM3750

ReturnLose (Singlemode)



UPC≥50dB

SPC≥55dB

APC≥60dB(typ.65dB)

Tested by JDSRM3750



Repeatability



±0.1dB



Operating temperature



-400C° to 850 C°



GeometryRequirement (Singlemode)



Ferrule Endface Radius

7mm≤R≤12mm(For APC)

10mm≤R≤25mm(For Standard)

Apex Offset≤30μm(For Master)

Apex Offset≤50μm(For Standard)

Under cut-50nmSU≤50nm

Tested by DORCZX-1



Recommed Products

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 0

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 1

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 2

Packing & Delivery



Packing:100/Pcs in one Carton box or OEM.

Shipment:by Sea,by Air,by Express:DHL/UPS/Fedex/EMS/TNT etc

Deliverty: 3-5 days after payment dowm,According to ur order quantity.

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 3





Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 4



Factory Pictures

Duplex OS2 9 125um SC to LC Single Mode Fiber Optic Patch Cord Low Loss 5



FAQ

1. Are you a manufacturer or trading company?
We are a direct manufacturer with 10 years of experience in fiber optic cable, FTTH drop cable and patch cord production. Our factory is located in Guangzhou.



2. How do you ensure quality?
All products are fully tested before shipment. Free samples are available after price confirmation.



3. Do you accept small orders?
Yes, small and trial orders are supported.



4. What is your delivery time?
Normally 3–7 working days depending on order quantity. Shipment is arranged promptly after payment.
